Custom Metal Progressive Die Press Dies Punching Tools Cold Stamping Die For Car

Product Type: Steel Progressive Die

Introduction:

TTM metal part progressive die press dies equipment is consitsed of by upper die base and Lower die set.

Part Materail is CR240LA:

1)50% Mild steel

2) 40% high strength including DP steel

3) 10% aluminum parts & the others

Die size: 2300L*1400W*700H


Product Detail

Product Tags

Progressive Die Producing Auto Parts Video

Progressive Die Overview

Place of Origin: Guangdong, China Brand Name: TTM
Model Number: Stamping tool/die Shaping Mode: Die Casting
Size: 4270L*2220W*1000H Usage: Automotive
Part Material: CR240LA-GI60/60-U Mould Life: 5-10 Years
Mould type: Progressive mould Certification: IS09001/TUV



Stamping Die Capability

Supply Ability:300 Sets per Year

Video Description

Products Description

Brand Name OEM
Product Name Metal Stamping Die/ Progressive Die
Tolerance +0.002mm
Material SKD11, SKD 61, Cr1 2MOV, D2, SKH9, RM56, ASP23 etc.
Design Software AutoCAD, Solid works, PRO/E, UG
Standard IS09001
Mould Type Compound Stamping Die, Single Stamping Die, Progressive die or according to Customer's requirements
First Trial 15-25 days after mold drawing confirmed
Mould Life Depends on customer S production capacity
Quality confirm Can send strip layout of die, testing video, inspection certificate and sample of product
Package PE bags and carton for products, wooden case for Die/mold, or as customer's requirements



Stamping Mould Packaging & Delivery

Sea Port options:Shen Zhen/ Guangzhou

Packaging Details:packed by wooden box/ wrapping flim

stamping die packing

TTM progressive die packing
